| Manufacturer： | WALTER |
| Product Series： | WALTER-WL55P |
| Product Type： | Power Fuse |
| EU RoHS： | Compliant(2011/65/EU) |
| EU REACH： | Dose not contain REACH SVHC(1907/2006/EC) |
{{cartItemsCount}}
| Manufacturer | WALTER |
| Product Series | WALTER-WL55P |
| Product Type | Power Fuse |
| series information | |
| Fuse Type | Power Fuse |
| Brand | WALTER |
| Manufacturer Series | WALTER-WL55P |
| Rated Current | 2.5A ;3A ;3.5A ;4A ;6A |
| Rated Voltage | 1500V DC |
| Operating Temperature | -55℃~125℃ |
| Storage Conditions | +10℃~60℃ |
| Safety Approvals | cULus |
| Breaking Capacitiy | 15KVDC/10KA;15KVDC/20KA |
| Size (Unit: mm) | |
| WL55-XXX | 10.3mm*57mm |
| WL55P-XXX-AP | 11.9mm*82mm |
| WL55P-XXX-I | 10.3mm*81.5mm |
| Installation Way & Parameters | |
| Installation Way | Stud-mount |
| EU RoHS | Compliant(2011/65/EU) |
| EU REACH | Dose not contain REACH SVHC(1907/2006/EC) |
